AruAL SlimLine W78FM IN

Aru AL Slimline1 W78F IN is a minimalist design for modern and energy-efficient buildings, featuring a pivot-hung window and balcony door with aluminium profiles on the outside throughout the frame and frame.

The window construction is exceptionally slim allowing maximum light to enter the rooms. The profile of the inner side of the window can be either rectangular or 15 degrees inclined. With a 52mm or 48mm triple glazing unit and double glazing, the window is durable and energy efficient.

Aluminium profiles are anodised or powder coated according to RAL catalogue. Together with the state-of-the-art ROTO locking system, the combination in perfect workmanship offers aesthetic pleasure and the best in ease of use and protection against both cold winter and hot summer.

AruAL SlimLine W78FM IN

Technical information

Download the product sheet here

  • Frame depth: 90,5 mm

  • Profile: Aru SlimLine1

  • Thermal transmittance: Uw=0.73 W/m²K

  • Standard glazing unit: triple glazing with two low-emissivity coatings

  • Glazing unit thickness: 24-52mm

  • Air permeability: Class 4

  • Resistance to wind load: C5

  • Watertightness: E1500

  • Sound insulation: Rw(C;Ctr)=32(-1;-5)dB
